Common Stability Study Setpoints
▣
25°C / 60% RH
Long-Term Condition
▥
30°C / 65% RH
Intermediate Condition
♨
30°C / 75% RH
Hot & Humid Condition
♨
40°C / 75% RH
Accelerated Condition
Study conditions must be selected according to the applicable protocol, product and regulatory market.
From Study Setup to Traceable Records
1
Define
User requirements
and study setup
and study setup
→
2
Select Setpoints
Choose study conditions
→
3
Load Samples
Organize study batches
→
4
Monitor
Real-time HMI overview
→
5
Records
Audit trail & reports
Designed for Stability Programmes
≋
Uniform Sample Storage
Controlled conditions support consistent studies.
◉
Continuous Monitoring
Critical and vital parameters remain visible on the HMI.
♧
Secure Alarm Management
Deviations, door opening and events are recorded.
▤
Flexible Shelving
Adjustable perforated SS trays organize multiple study batches.
▣
Observation Window
View samples without opening the primary door.
Data Integrity & User Control
Aligned with 21 CFR Part 11-ready configuration
♙
User Access Levels
Role-based access levels for operators and reviewers.
▢
Password-Protected Settings
Critical parameters are protected from unauthorized changes.
▤
Audit Trail
Automatic audit trail of configuration changes and events.
♙
Operators Log
Track user logins, logouts and activity.
♧
Alarm History
All alarm events are time-stamped and stored for review.
▤
Programmable Recording Interval
Set custom recording intervals for study parameters.
Technical Specifications
A Performance
Temperature Range: 20°C to 60°C
Temperature Accuracy: ±0.5°C
Temperature Uniformity: ±1°C
Humidity Range: 40% to 95% RH
Humidity Accuracy: ±3% RH
Humidity Uniformity: ±5% RH
Temperature Accuracy: ±0.5°C
Temperature Uniformity: ±1°C
Humidity Range: 40% to 95% RH
Humidity Accuracy: ±3% RH
Humidity Uniformity: ±5% RH
B Construction
Interior: Single atmospheric chamber
Exterior: SS 304 stainless steel
Insulation: PUF / CFC-free PUF
Door: Double-door configuration
Shelves: Perforated SS trays
Chamber Capacity: Custom
Outer Dimensions: Custom
Exterior: SS 304 stainless steel
Insulation: PUF / CFC-free PUF
Door: Double-door configuration
Shelves: Perforated SS trays
Chamber Capacity: Custom
Outer Dimensions: Custom
C Controls & Utilities
Controller: PLC-based programmable controller
Display: Capacitive touchscreen HMI
Data Logging: Temperature, humidity and alarms
Programming: Ramp-and-soak profiles
Power Supply: 230 VAC, single phase, 50 Hz
Power Consumption: Product dependent
Compliance: 21 CFR Part 11-ready package
Display: Capacitive touchscreen HMI
Data Logging: Temperature, humidity and alarms
Programming: Ramp-and-soak profiles
Power Supply: 230 VAC, single phase, 50 Hz
Power Consumption: Product dependent
Compliance: 21 CFR Part 11-ready package
Engineered for
Continuous Stability Storage
Continuous Stability Storage
♨
Air Heating
Stable temperature
control
control
❄
Refrigeration
Humidity controlled
cooling system
cooling system
≋
Steam Humidification
Accurate moisture
control
control
◉
Forced-Air Circulation
Uniform conditioned
airflow
airflow
▯
Door Sealing
Secure gasket and
positive locking
positive locking
▤
Adjustable Shelving
Flexible fit for
product positioning
product positioning
Active Monitoring and Protection
✓
Temperature
Deviation
Deviation
♨
Humidity
Deviation
Deviation
◉
Compressor
Protection
Protection
♧
Alarm
Management
Management
▯
Door-Open
Interlock
Interlock
↑
Over-Temperature
Protection
Protection
Stability Testing Applications
⚗
Drug
Substances
Substances
▤
Finished
Formulations
Formulations
◇
Primary
Packaging
Packaging
◫
Light-Protective
Packaging
Packaging
◇
Pharmaceutical
R&
R&
♧
Pharmaceutical
R&D
R&D
Need Help Choosing the Right Equipment?
Tell us about your application and laboratory requirements. Our team will help
you compare suitable options and select the equipment that best fits your needs.
