CE-marked configuration•U.S. clinical availability•Regulatory status may vary by country
System Highlights
◎
Ultra-Fine Manipulation
Smooth coarse and fine control for precise micropipette positioning.
≋
Thermosafe™ Temperature Control
Warm airflow supports uniform Petri-dish temperature.
↗
Rapid Pipette Setup
One-step angle adjustment supports quick micropipette changes.
▦
Integrated XY Stage
Large heated mechanical stage for controlled dish movement.
♡
Touchscreen Operation
3.5-inch colour display for temperature, timer and injection count.
♙
Nikon ICSI Optics
Stable integrated platform with 1.0x/1.5x magnification switching.
Technical Specifications
| Micromanipulator | RI Integra 3™ with dual manipulators |
| Microscope | Nikon ECLIPSE Ti2-U IVF |
| Heating System | Thermosafe™ air heating with heated metal insert |
| Temperature Range | 30–45°C |
| Temperature Accuracy | Better than ±0.1°C when calibrated |
| Temperature Resolution | 0.1°C |
| Display | 3.5-inch colour LCD touchscreen |
| Imaging Connectivity | USB connection for RVI Viewer™ |
| Microscope Optical System | Infinity-corrected CFI60 |
| Intermediate Magnification | Manual 1.0x / 1.5x switching |
| Power Input | 100–240 VAC, 50–60 Hz |
| System Footprint | 56 × 38 cm, excluding microscope |
Control, Imaging & Syringe Options
⚕
SAS™ Air Syringes
Two air syringes supplied in standard configurations.
◇
SOS™ Oil Syringe
Quick-fill oil control available as a configuration option.
▣
Camera Integration
Capture photographs and video using shortcut controls.
▣
RI Viewer™ Software
Full-screen imaging, digital magnification, measurement and training simulator.
Thermosafe™ Thermal Protection
≋
Uniform Warm Air
Gentle airflow directed beneath the culture dish.
♨
Temperature Monitoring
Status indicator plus audible and visible deviation alarms.
♧
Alarm Logging
Triggered temperature alarms are recorded for review.
Designed for Assisted Reproduction Procedures
◎
ICSI
◉
IMSI
❉
Embryo Biopsy
For trained embryology and assisted-reproduction professionals.
☏
Need Help Choosing the Right Equipment?
Tell us about your application and laboratory requirements.Our team will help you compare suitable options and selectthe equipment that best fits your needs.
