Key Advantages
⇥
HEPA-Filtered Airflow
Continuously unidirectional HEPA-filtered airflow maintains a cleaner transfer environment.
+
Positive-Pressure Chamber
Positive pressure inside the chamber helps prevent backflow of contaminants.
▣
Door Interlocking
Mechanical or electromagnetic interlocking prevents both doors from being open simultaneously.
⚙
Integrated Blower
Built-in blower maintains consistent airflow performance.
▤
Clear Viewing Window
Transparent observation window for visual confirmation.
◉
Optional UV Lamp
Optional UV lamp supports additional disinfection.
Technical Specifications
| Working Principle | Material transfer through a chamber supplied with HEPA-filtered air |
| Airflow | Continuous unidirectional HEPA-filtered airflow |
| HEPA Filter | 99.99% efficiency at 0.3 micron or higher |
| Blower | Integrated blower |
| Pressure Control | Positive pressure inside the chamber |
| Contamination Control | Continuous flushing of airborne particles |
| UV Lamp | Optional |
| Door Interlocking | Mechanical or electromagnetic |
| Cleanliness Level | ISO Class 5 / Class 100 working environment |
| Application | Transfer from a lower-grade area to a higher-grade cleanroom |
| Construction | Stainless-steel chamber and doors |
| Viewing Window | Transparent observation window |
| Mounting | Wall-mounted configuration |
Suitable Applications
◒
Pharmaceutical
Cleanrooms
Cleanrooms
⚗
Microbiology
Laboratories
Laboratories
⚙
Sterile
Manufacturing
Manufacturing
⚗
Chemical
Laboratories
Laboratories
Built for Contamination-Controlled Transfer
≋
HEPA Air Purge
Filtered airflow flushes airborne particles from the chamber.
+
Positive-Pressure Chamber
Maintains positive pressure inside the chamber to reduce infiltration.
▣
Interlocked Door Control
Interlocking doors prevent simultaneous opening for controlled transfer.
♧
Need Help Choosing the Right Equipment?
Tell us about your application and laboratory requirements. Our team will help you compare suitable options and select the equipment that best fits your needs.
