Key Advantages
♧
Recipe-Based Programs
Create and save repeatable growth
protocols for consistent results.
protocols for consistent results.
☼
Sunrise/Sunset Ramping
Programmable light and setpoint
transitions that mimic natural cycles.
transitions that mimic natural cycles.
▤
Multi-Tier LED Lighting
Full-spectrum LED arrays on multiple
levels for uniform plant illumination.
levels for uniform plant illumination.
✤
Uniform Air Distribution
Forced-air circulation maintains even
temperature and humidity throughout.
temperature and humidity throughout.
☁
Remote Monitoring Option
Monitor and manage the chamber
remotely for greater convenience.
remotely for greater convenience.
▣
USB Data Export
Export logged data via USB for easy
analysis and record-keeping.
analysis and record-keeping.
Technical Specifications
Configuration
Single programmable controlled-environment chamber
Chamber Capacity
500 litres; custom capacities available
Temperature Range
10°C to 50°C with light ON
Temperature Accuracy
±0.5°C
Temperature Uniformity
±1°C
Humidity Range
40% to 90% RH
Humidity Accuracy
±3% RH
CO₂ Range
350 to 2,000 ppm, adjustable
Lighting
Full-spectrum LED growth lighting
Light Control
0–100% programmable dimming
Lighting Arrangement
Multi-tier, height-adjustable LED modules
Air Circulation
Uniform forced-air circulation
Fresh-Air Intake
Adjustable, HEPA-filter provision
Controller
PLC / IoT-based programmable controller
Display
7-inch capacitive touchscreen HMI
Interior
SS 304 stainless steel
Exterior
Powder-coated mild steel
Shelves
Four adjustable perforated SS shelves
Observation
Double-glazed transparent observation window
Insulation
CFC-free PUF insulation
Data Logging
Temperature, humidity, CO₂, and light records
Power Supply
230 VAC, single phase, 50 Hz
Ranges, chamber capacity and lighting configuration can be customized.
Suitable Applications
♧
Plant Phenotyping
♧
Crop Stress Studies
♧
Plant Physiology
▱
Controlled
Agriculture R&D
Agriculture R&D
◇
Academic Research
Built for Complete Environmental Control
Coordinated Environmental Control
♧
♨
✤
💧
☼
☁
Create and repeat coordinated
environmental profiles from one
touchscreen interface.
environmental profiles from one
touchscreen interface.
Programmable Day & Night Simulation
06:00
Ramp Up
Ramp Up
08:00
Day Setpoint
Day Setpoint
18:00
Ramp Down
Ramp Down
20:00
Night Setpoint
Night Setpoint
☼
☀
☼
☾
♨ Temperature
💧 Humidity
☁ CO₂
☼ LED Intensity
Illustrative schedule; all setpoints are configurable
for the research protocol.
for the research protocol.
Monitoring & Protection
♨⚠
Temperature
Deviation
Deviation
💧⚠
Humidity
Deviation
Deviation
☁⚠
CO₂
Deviation
Deviation
☼
Light
Failure
Failure
▯
Door
Open
Open
💧
Low Water
Level
Level
Audio-visual alarms, over-temperature
protection, compressor delay and
automatic water-level safeguards.
protection, compressor delay and
automatic water-level safeguards.
